Product Description

Description

The new CRL330 Series are designed as a direct replacement for original equipments incandescent rear combination found on Hino and other Japanese styled trucks. The CRL330 Series is made for heavy duty use which features a high impact acrylic lens and strong ABS Base, and is suited to OEM and commercial vehicle applications.Perfect for upgrading existing incandescent lamps to LEDs.



Features

  • • 9 - 33 Volt DC integrated circuitry
  • • Horizontal top or back screw mounting
  • • Retrofits same style lamp series
  • • 0.5m Cable
  • • Fully ADR compliant

Specifications

Specifications

Applications •Retrofit Japanese Trucks
Functions Stop / Rear Position / Direction Indicator / Reflector
Voltage 9-33V DC VarivoltÆ
Wattage Stop:2.2Watt

Rear Position:0.5Watt

Indicator: 1.8Watt
Mounting Horizontal top or back screw mounting
Materials High impact acrylic lens, ABS Body / Heavy duty ABS base
Environmental IP67
Cable Length 0.5M
Dimensions 326x202x38mm
ADR Compliance Stop & Rear Position:49/00, Rear Direction Indicator:6/00:Cat2a, Rear Retro Reflector:47/00
CRN Stop - Pending, Tail - Pending, Direction - Pending, Refector - Pending

Parts List

CRL330LEDLH 330 Series Combination LED 9-33V Stop / Tail / Indicator / Reflector (LH)
CRL330LEDRH 330 Series Combination LED 9-33V Stop / Tail / Indicator / Reflector (RH)
